| Functions |
The LD 3000 hardness tester is a very practical and strong
instrument designed to perform Brinell hardness tests at
3000 kg and other loads starting from 10Kg and also to
perform Vickers tests. The integral AFFRI system assures
high performance using automatic selection and application
of loads through a simple touch panel. Digital readout of
load force and dwell time help the operator during the
test. The test force is closed loop controlled through an
electronic load cell connected to the indenter. All errors
linked to weight systems are eliminated, the test is fast
and there is an absolute increase in accuracy in every
condition.
It includes a clamping cap for secure stability of large
parts. The indenter moves through 30 mm into auto contact
with the sample.
The operator is required only to push the twin start
buttons to initiate the complete test sequence: auto
contact with the test surface ,clamping, application of
the test loads, release of sample. At the end of the
cycle, the operator can easily measure the indentation in
different systems:
- EASYBRINELL, which is the electronic microscope
for automatic measure (it is an option).
It can be operated in areas subject to vibration.
No need to level.
It can work even if inclined.
It can be operated at different temperature ranges from 0
to 50°C.
|
|
Performance
|
Brinell hardness tester upgrading for Rockwell,
Vickers.
basic configuration includes Optic Brinell
microscope for fast measure of indentations.
as option can be installed automatic optic
Microscope EASY SCAN and many other accessories.
|
|
|
 |
 |
clamping base for large
and unstable pieces
|
brinell hardness
