| Functions |
- Unparalleled Accuracy, Repeatability and
Reproducibility under
all test conditions which can be verified under
operational conditions R. R. within 8 -
Measurement of load and indenter penetration on a
common axis, giving an absolute hardness result.
- Graphical illuminated display to obtain clear
and accurate readings. Icons facilitate operator
identification of software functions.
- Signal of test cycle end to aid the operator.
- Automatic control and -select-ion of
pre-loads and
main loads using closed-loop load control.
- Single button operator -select-ion of test load
and measurement scale.
- Simultaneous conversion between different scales
(Rockwell, Brinell, Vickers and tensile stress
N/mm2).
- High precision rapid testing.
- The instrument and its controls are
ergonomically provided with security devices
according to CE norms.
- Effective statistics software incorporated with
printer or computer connection for: diagram,
graph, test summary, average, standard deviation.
- Software includes -set-tings in three
-select-able classes to facilitate integration of
the instrument into automatic lines.
- Programmable load dwell time 0.1 second
increment.
- Automatic correction on round surfaces and
storage of results.
- High resolution of measurement 0.1 (or 0.01 HR
unit on request).
- Reversion from automatic to semi-automatic mode
for single tests.
- Two years full warranty as
assurance of the high technical quality.
- Wide range of accessories in order to
accommodate pieces of different shapes.
CERTIFICATION
- Supplied with certificates on SIT primary
samples |
|
|
Performance
|
INGLE INITIATION OF COMPLETE OPERATION
INCLUDING AUTO CONTACT WITH TEST PIECE
- Perfect and effective measurements including the
first test.
- Insensitive to deflections even if very
important as 50mm.
- The long stroke head permits easy tests on
different height components without the need to
change the elevating screw position every time.
- The head moves down automatically into contact
and executes the test cycle.
- Following initiation by the Start button, the
250 MRS hardness tester head moves down to take
contact with the test surface in distance
multiples of 50 mm as part of the continuous test
sequence comprising:
- approach to the piece.
- clamping of the piece.
- indentation.
- complete measurement cycle and release of piece.
- Meets all laboratory requirements.
- Full operation even in presence of vibrations,
sudden changes in temperature or dusty
environments.
- Large range of test loads from 98.1 to 1839N
automatic selectable.
SIMPLE AND UNIVERSAL
- Easy and quick Rockwell, Super Rockwell,
Brinell, Vickers measures in a single machine.
- Every environmental condition is tolerable:
presence of dust, vibration, changes of
temperature.
- Wide software functions, information guide and
Windows icons - Immediate conversions.
- Statistics and connection to printer with
diagrams and graphs.
VERY HIGH PERFORMANCE
- Unaltered operation on 250 MRS hardness tester
even in extreme conditions: irregular pieces,
unfinished pieces, that are raised or misaligned,
every kind of support (lifting screw, deformable
materials, etc.) presence of impurities (dust,
oil, etc.) between the test piece and the support
or between the support and the point of the
support.
|
|
|
|
|
 |
 |
| Automatic Clamping |
Digital Control Panel |
|
